Elpro LIBERO Ti1 TempLogger PQS E006/024

General description:
The LIBERO Ti1 PDF Logger is a user programmable multi-use data logger with multiple alarm levels that automatically generates a report in PDF format upon connection to a USB port. No equipment and no software is required to read out logger. Release products based on the OK or ALARM status on the display, retrieve the PDF report and forward it to the sender for further analysis or archive it locally.

Key features:
-up to 6 temperature alarm levels with single or cumulative delays
-Customizable text area for additional information (e.g. shipment information, instructions, etc.)
-Chart visualizing the temperature curve and alarm limits

WHO PQS number: E006/024
Specification reference: E06/TR05.1
Product verification protocol: E06/TR05.VP.1

Technical specifications:
Operating temperature: -35°C to +70°C
Alarm display: Visual
Display medium: LCD
User interface: USB for computer
Minimum logging interval: 1 Minute user programmable
Accuracy: ±0.2°C
Battery type: Non-replaceable Li Mn
Battery shelf life: 14 Months, no activation.
Activated life: 400 Days
IP rating: IP 65

Packaging and labelling:
Cardboard box: 1 Box = 10 units
Volume per box: 0.001 m³
Weight per box: 0.38 Kg
Unit Weight: 0.038 Kg
Unit Dimensions: 9.5 x 4.0 x 1.2 cm

Warranty:
The product is covered by a one-year replacement warranty in the event of any component failure not caused by mechanical damage.
