Mains Ref. Vestfrost MK304 E003/007

Technical Guidance:
Contact with UNICEF Supply Division, HTC, Cold Chain Unit for technical questions. CPHHQ-SD-Cold Chain Unit < coldchainunit@unicef.org >

General Description:
Mains powered, Ice-lined refrigerator.
Model: Vestfrost MK304
PQS ref. E003/007

Technical specifications:
Net vaccine storage volume: 105 L
Power requirement: 220-240V 50/60Hz or 100-127V 50/60Hz.
Refrigerant type: R134a
Ambient operating temperature: Min. +5°C, Max. +43°C
Vaccine storage volume category: ≥90 - <120L

Supplied with:
1.Temperature Monitoring Device: 30-day electronic refrigerator temperature logger: Berlinger Fridge-Tag 2, E006/020 attached to internal refrigerator basket
OR
Upon request: Either Berlinger Fridge-Tag 2E, E006/040 with an internal sensor attached to internal refrigerator basket or Fridge-Tag 2E with external sensor, E006/040 shall be supplied
2.Voltage regulator: Stand-alone, Sollatek, model SVS04-22 for 220-240 volt 50/60 Hz or SVS04-11 for 100-127 volt 50/60Hz input voltage.
Upon request extended type Stand-alone voltage regulator, Sollatek, Model SVS04E-22, 230V 50/60Hz nominal output, 100-290V input voltage regulation range. Or Stand-alone, Bluebird Power Controls, Model BB 211, 230V 50/60Hz nominal output, 110-278V input voltage regulation range.
Stand-alone, Sollatek, Model SVS08-11, 120V 50/60Hz nominal output, 80-160V input voltage regulation range. Or Stand-alone, Bluebird Power Controls, Model BB 186, 120V 50/60Hz nominal output, 82-159V input voltage regulation range.
3.Appliance as standard fitted with sealed-on Schuko plug, power lead 1.5m
4.Lid with lock, plus 2 keys and 7 baskets.

Manuals:
User, Installation and Technician’s manual as outlined in PQS Specifications E003/RF03.3 will be supplied.

Shipping Information:
Packaging and labelling;
Estimated shipping weight: 121 kg
Estimated shipping volume: 0.94 m³

Warranty:
The product is covered by a two year replacement warranty in the event of any component failure arising from defective design, materials or workmanship.

NOTES:
UNICEF CO or partners should notify the voltage & frequency to ensure correct choice of freezer and voltage regulator.
A label, displaying vaccine storage advice & user instructions with pictures is permanently mounted on cabinet. Label is in the UN languages (Arabic, English, French, Mandarin Chinese, Russian or Spanish, or other language be available on demand).
Maintenance tool kits are available on request. (For contents, see supply web catalogue.)
One set of spare parts is recommended but not compulsory for every 10 units of ILRs.
Further information for comparable products, can be obtained from CPHHQ-SD-Cold Chain Unit < coldchainunit@unicef.org >.
